SPECIFICATIONS AMPLIFIER Continuous average power output (FTC) Front L/R: 50 W per channel min. RMS at 8Ω, 2 channels driven at 1kHz with no more than 0.05% total harmonic distortion. Frequency response: 20 Hz to 50 kHz: 0/–3 dB Signal-to-noise ratio: 95 dB (S1, IHF-A) Total harmonic distortion: 0.05% at rated power Damping factor: 60 at 8Ω Input sensitivity and impedance: 720 mV/22 kΩ (Unbalanced) Output level and impedance Pre out (Z1 - Z4 L/R): +16 dB/680Ω Speaker impedance: 6Ω to 16Ω VIDEO SECTION Input level and impedance (S1 - S8): 1 Vp-p/75 (Composite) GENERAL Power supply: AC 120 V, 60 Hz Power consumption: 4.0 A Standby power consumption: 21.4 W Dimensions (W x H x D): 17-1/8 x 5-5/8 x 15-13/16 435 x 173.5 x 428.5 mm Weight: 27.8 lbs. (12.6 kg) Optional mounting kit: IRK-130-4 U dimension: 3U Multi-Source Multi-Zone Amplifier Optional Keypads KEY-2.7 KEY-5.7 FEATURES - Customizable source button name/layout- Standby, mute, volume up/down, 6 source select presets - Volume level and power on status indicators- Plasma friendly IR receiver FEATURES Same as KEY-2.7 plus: - Backlit buttons - 10-Button numeric keypad - Transport and skip functions - Dual function/long press programmable buttons - IR learning capability - Firmware upgradeable Due to a policy of continuous product improvement, Integra reserves the right tochange specifications and appearance without notice. 2/2008 Printed in the USA Designed to Integrate. Built to Stimulate. www.integrahometheater.com MZA-4.7
